Mars Global Surveyor
Mars Orbiter Camera




Pictures Provided to the ASU Mars K-12 Education Program for the
September 2000 Death Valley/Mono Valley Comparative Planetology Tour

These pictures were used by educators comparing landforms in Death Valley, California, with features on the surface of Mars. The pictures are Mars Global Surveyor Mars Orbiter Camera images processed for the ASU Mars K-12 Education Program by Malin Space Science Systems. The pictures were selected by Sheri Klug, director of the ASU Mars K-12 Education Program, and Ken Edgett, the former director of ASU program. All data used for this project were in the public domain. These processed, value-added views should be credited to NASA/JPL/Malin Space Science Systems.

Pictures prepared by Ken Edgett, Malin Space Science Systems, August 23, 2000




Sand Dunes and Other Eolian (Wind) Features:

(1)

M01-00179
barchan and seif (linear) dunes in N Polar region
lat/lon 82.2 N 76.5 W
North toward upper left
picture is 3 km wide
resolution is about 3 m/pixel
Sun from lower left
Full image at: http://www.msss.com/moc_gallery/images/M0100179.html


(2)

M02-03118
sand dunes in N polar region
lat/lon 81.1 N 83.5 W
North toward right/upper right
Picture is 1.5 km wide
resolution is about 3 m/pixel
Sun from lower left
Full image at: http://www.msss.com/moc_gallery/images/M0203118.html


(3)

M02-02835
sand dunes in N polar region
lat/lon 78.7 N 255.1 W
North toward top
Picture is 3 km wide
resolution is about 3 m/pixel
Sun from lower left
Full image at:http://www.msss.com/moc_gallery/images/M0202835.html


(4)

FHA-00451
Sand dunes on caldera floor, Nili Patera, Syrtis Major
lat/lon 8.9 N 292.8 W
North toward upper right
picture is 3 km wide
resolution is 3 m/pixel
Sun from lower left
Full image at: http://www.msss.com/moc_gallery/images/FHA00451.html


(5)

M02-00783
barchan dunes and a single seif (linear) dune in N polar region
lat/lon 84.4 N 26.4 W
North toward right/upper right
picture is 1.5 km wide
resolution is 3 m/pixel
Sun from lower left
Full image at:http://www.msss.com/moc_gallery/images/M0200783.html


(6)

M04-04064
wind streak in W Mangala Valles
lat/lon 9.6 S 152.9 W
North toward upper right
Picture is 3 km wide
Resolution is about 3.7 m/pixel
Sun from left/lower left
Full image at:http://www.msss.com/moc_gallery/images/M0404064.html



Layered Outcrops

(1)

M02-00583
layered outcrop in valley off E side of Elysium Rise
lat/lon 24.3 N 206.3 W
North toward upper right
picture is 1.2 km wide
resolution is 1.5 m/pixel
Sun from lower left
Full image at: http://www.msss.com/moc_gallery/images/M0200583.html


(2)

M00-01148
upper wall of Ius Chasma Tributary
lat/lon 8.5 S 83.8 W
North toward lower left
picture is 1.2 km wide
resolution is about 1.8 m/pixel
Sun from right/upper right
Full Image at: http://www.msss.com/moc_gallery/images/M0001148.html


(3)

M03-02733
layer outcrop in Holden Crater
lat/lon 27.1 S 34.7 W
North toward upper right
Picture is 3 km wide
Resolution is about 3.7 m/pixel
Sun from left/upper left
Full image at: http://www.msss.com/moc_gallery/images/M0302733.html


(4)

M03-04846
S polar layer outcrop in wall of Chasma Australe
lat/lon 83.0 S 258.6 W
North toward upper right
Picture is 3 km wide
Resolution is 6 m/pixel
Sun from upper left
Full image at: http://www.msss.com/moc_gallery/images/M0304846.html


(5)

M02-04253
impact crater with layers in wall, Acidalia Planitia
lat/lon 37.1 N 37.8 W
North toward upper right
Picture is 3 km wide
resolution is about 3.7 m/pixel
Sun from lower left
Full image at: http://www.msss.com/moc_gallery/images/M0204253.html


(6)

M04-00795
layers in upper wall of Hebes Chasma, Valles Marineris
lat/lon 1.9 S 74.0 W
North toward lower left
Picture is 1.5 km wide
Resolution is 3 m/pixel
Sun from right
Full image at: http://www.msss.com/moc_gallery/images/M0400795.html



Playa-Like Features (probably caused by deflation, not real playas)

SP1-24205
bright playa-like deflation patches in troughs in Memnonia
lat/lon 8.0 S 167.8 W
North toward upper right
Picture is 12.1 km wide
Resolution is about 11.8 m/pixel
Sun from right/lower right
Full image at: http://www.msss.com/moc_gallery/images/SP124205.html



Impact Craters and Volcanic Craters/Pits to Compare with Ubehebe Crater

(1)

FHA-01118
impact crater in NW Elysium Planitia
lat/lon 20.3 N 244.5 W
North toward upper right
picture is 3 km wide
resolution is about 3.7 m/pixel
Sun from left/lower left
Full Image at: http://www.msss.com/moc_gallery/images/FHA01118.html


(2)

M02-02296
impact craters in W Arabia Terra
lat/lon 30.3 N 13.6 W
North is toward upper right
Picture is 3 km wide
resolution is 3 m/pixel
Sun from left
Full image at: http://www.msss.com/moc_gallery/images/M0202296.html


(3)

M03-07094
volcanic pits and channel on S flank of Ascraeus Mons
lat/lon 9.5 N 105.3 W
North toward upper right
Picture is 3 km wide
Resolution is about 3.7 m/pixel
Sun from left
Full image at: http://www.msss.com/moc_gallery/images/M0307094.html


(4)

SP2-50704
small elliptical volcano/caldera in Tempe Terra
lat/lon 36.2 N 85.1 W
North toward upper right
Picture is 3.3 km wide
Resolution is about 3.9 m/pixel
Sun from right/lower right
Full image at: http://www.msss.com/moc_gallery/images/SP250704.html


Other Pictures of Interest:

(1) Melas Chasma layer outcrops and ridges (dunes?)
http://www.msss.com/mars_images/moc/may_2000/layers/

(2) "Seepage" gullies
http://www.msss.com/mars_images/moc/june2000/

(3) dust devil streaks
http://www.msss.com/mars_images/moc/lpsc2000/3_00_dustdevil/

(4) "Monument Valley"
http://www.msss.com/mars_images/moc/6_3_99_mesas/index.html
