Mars Global Surveyor
Mars Orbiter Camera
The Textured Surface of Alba Patera Volcano
MGS MOC Release No. MOC2-159, 19 July 1999
570 KByte gif --
290 KByte gif
The Alba Patera volcano is the northernmost of the Tharsis volcanoes
on Mars. It is a very low, flat volcano that has slopes that are typically
less than one degree. The lava flows and channels on the flanks of
the Alba Patera volcano are mostly obscured by a covering of eroded,
lumpy-textured material of unknown origin. A surface covered by this material
is shown here. The large crater (upper left) probably formed by meteorite
impact, but it has been subsequently modified and now appears to be partly
exhumed from beneath a covering of the rough, lumpy material.
The surface material could be a deposit of thick, eroded volcanic ash.
Alternatively, it could be thick, eroded, windblown dust. Or something
else. No one knows. This Mars Global Surveyor Mars Orbiter Camera image
was taken in July 1998 and is illuminated from the lower right.
Malin Space Science Systems and the California Institute of Technology
built the MOC using spare hardware from the Mars Observer mission. MSSS
operates the camera from its facilities in San Diego, CA. The Jet Propulsion
Laboratory's Mars Surveyor Operations Project operates the Mars Global Surveyor
spacecraft with its industrial partner, Lockheed Martin Astronautics, from
facilities in Pasadena, CA and Denver, CO.
