MGS MOC Release No. MOC2-172, 10 August 1999
The four still-frame images (above) show the evolution of a storm system that developed over the martian north polar region on June 30, 1999. Each picture was taken approximately 2 hours later than the previous. The north polar ice cap is the white feature at the center of each frame. Clouds that appear white consist mainly of water ice, clouds that appear orange/brown contain dust.
This particular storm system lasted well into the next day--July 1, 1999. A total of 23 red and 23 blue camera images were used to create a time-lapsed "movie" that displays the development and evolution of this storm over the two-day period. Of great interest are the "curling" of the clouds behind the largest of the storms--this indicates a flow vortex that follows the storm front that is moving toward the top/upper right of the frame--and the correlation of white water-ice clouds with orange/brown dust clouds. High surface winds must have raised dust and mixed it with water vapor in the air over the summer-time polar cap to create this effect. To view the "movie," click or download to your desktop the following 2.2 MByte MPG file.
Storms similar to those shown here were observed to continue throughout the month of July and into August. Over the next several months, the north polar cap will grow dark as the region transitions through autumn and into winter. When northern winter begins in December 1999, this region will be dark and obscured by clouds.
Malin Space Science Systems and the California Institute of Technology built the MOC using spare hardware from the Mars Observer mission. MSSS operates the camera from its facilities in San Diego, CA. The Jet Propulsion Laboratory's Mars Surveyor Operations Project operates the Mars Global Surveyor spacecraft with its industrial partner, Lockheed Martin Astronautics, from facilities in Pasadena, CA and Denver, CO.
