Mars Global Surveyor
Mars Orbiter Camera

A Valley in the Libya Montes

MGS MOC Release No. MOC2-227, 22 May 2000


50% Size View 165 KBytes
Full Resolution View 740 KBytes

Full Resolution View #1 280 KBytes
Full Resolution View #2 280 KBytes

This Mars Global Surveyor Mars Orbiter Camera narrow angle image (above left) shows an intermountain valley floor in the Libya Montes region of Mars. Its regional setting is seen in the wide angle color mosaic on the right (above). The Libya Montes were formed by the giant impact that created the ancient Isidis basin. The Libya mountains and valleys--like the one shown here--were subsequently modified and eroded by other processes, including wind, impact cratering, and flow of liquid water to make the small valley that runs across the middle of the scene. Until the mission was canceled, the Libya Montes region was among the top two candidates for the Mars Surveyor 2001 lander. This image, illuminated by sunlight from the left, covers an area 3 kilometers (1.9 miles) wide and 19 kilometers (11.8 miles) long. The scene is located near 1.5°N, 278.4°W and was acquired on June 27, 1999. The high resolution color view (above left) was created by combining the colors derived from Mars Orbiter Camera Wide Angle views of the region obtained in May 1999 with the high resolution view obtained in June 1999.

Other Image Viewing Options:

50% Size View 1.0 MBytes
Full Resolution View 4.5 MBytes

Full Resolution View #1 1.0 MBytes
Full Resolution View #2 1.1 MBytes

Images Credit: NASA/JPL/Malin Space Science Systems

Malin Space Science Systems and the California Institute of Technology built the MOC using spare hardware from the Mars Observer mission. MSSS operates the camera from its facilities in San Diego, CA. The Jet Propulsion Laboratory's Mars Surveyor Operations Project operates the Mars Global Surveyor spacecraft with its industrial partner, Lockheed Martin Astronautics, from facilities in Pasadena, CA and Denver, CO.
