MRO MARCI Weather Report for the week of
3 December 2007 – 9 December 2007

Captioned Image Release No. MSSS-6 — 12 December 2007

Martian Weather Between 3 and 9 December 2007:

There is no weather report for the 3–9 December 2007 period. The Mars Reconnaissance Orbiter (MRO) Mars Color Imager (MARCI) camera was powered-up on Monday, 3 December, but did not resume collecting new data before the end of this weather reporting period.

Thus, for your viewing pleasure, we present here a movie and report from data acquired by MARCI during the week of 7–13 October 2007. Please click and play the Quicktime movie (.mov file) to see how the weather on Mars changed during that time.

Martian Weather Between 7 and 13 October 2007:

Weather conditions in October were just returning to seasonal norms, as the red planet continued to recover from a rare planet-encircling dust event. Skies remained slightly dusty across most of the planet. The last of the large regional dust storms for this Mars year can been seen at northern mid-latitudes along the seasonal polar cap edge, moving eastward from Acidalia to Utopia in the general polar circulation. The storm spread southward into the subtropics upon reaching Utopia. But just as quickly the storm dissipated, leaving behind a remnant dust haze by weeks end. In the southern hemisphere, atmospheric conditions were fairly uninteresting, no afternoon dust storm activity and the only water ice clouds were seen in their usual location over the Tharsis volcanos.

Earlier Mars Weather Reports are available HERE.

About the Quicktime Movie:
The movie (a .mov file that you can click and play, above) was generated from images obtained by the Mars Color Imager (MARCI) onboard the Mars Reconnaissance Orbiter (MRO). During a nominal operational week, a total of about 273 MARCI images, taken in three of the camera’s seven color filter bands (420, 550, and 600 nanometer wavelengths), are map projected and mosaiced together to produce seven false-color daily global maps. These maps are then projected onto a sphere with north at the top and east to the right and with the mid-afternoon vantage point of an observer in the orbital plane (the imaginary plane that the planet draws out as it circles the Sun). Black areas in the movie are the result of data drops or high angle roll maneuvers by the spacecraft that limit the camera’s view of the planet. Equally-spaced blurry areas that run from south-to-north (bottom-to-top) result from the high off-nadir viewing geometry, a product of the spacecraft’s low-orbit, 250 km x 316 km (155 miles x 196 miles). The movie is rendered at a lower resolution than the intrinsic 1–2 km nadir resolution that the MARCI provides, so that it is practical to view and share via the Internet. The small white circles on these images of Mars indicate the locations of the two Mars Exploration Rovers, Opportunity (on Meridiani Planum) and Spirit (in Gusev Crater). Other locations on Mars referenced in the weather report can be found by referring to the map below. Note that the still image of Mars depicted at the top of this page is a single frame from the Quicktime movie.

Reference Map — Martian Place Names Commonly Mentioned in Mars Weather Reports simple cylindrical map of Mars with various place names indicated
NASA/JPL/Malin Space Science Systems

Citation and Credit
The image(s) and caption are value-added products. MSSS personnel processed the images and wrote the caption information. While the image(s) are in the Public Domain, NASA/JPL/MSSS requests that you credit the source of the image(s). Re-use of the caption text without credit is plagiarism. Please give the proper credit for use of the image(s) and/or caption.

Image Credit:
NASA/JPL/Malin Space Science Systems

To cite the image(s) and caption information in a paper or report:
Malin, M. C., B. A. Cantor, J. A. Lougen and K. S. Edgett (2007), MRO MARCI Weather Report for the week of 3 December 2007 – 9 December 2007, Malin Space Science Systems Captioned Image Release, MSSS-6,

Malin Space Science Systems (MSSS) built and operates the Mars Reconnaissance Orbiter (MRO) Mars Color Imager (MARCI) and Context Camera (CTX). MSSS also built and operated the Mars Global Surveyor (MGS) Mars Orbiter Camera (MOC). In addition, MSSS built the Mars Odyssey (ODY) Thermal Emission Imaging Spectrometer (THEMIS) Visible (VIS) camera subsystem, which shares optics with the thermal infrared instrument and is operated at Arizona State University (ASU). MSSS also built the Mars Descent Imager (MARDI) cameras for the Mars Polar Lander and Phoenix Mars lander missions, and the MARCI onboard the Mars Climate Orbiter. Currently, the company is building cameras for the 2008 Lunar Reconnaissance Orbiter, 2009 Mars Science Laboratory rover and the 2011 Juno mission to Jupiter.
