New Impact Crater in Arabia Terra

MGS MOC Release No. MOC2-1613, 6 December 2006

(A) MOC2-1613-a
Colorized view of impact site; small crater at center of very extensive dark rays, rings, and chains of secondary pits.
No Annotation
(B) MOC2-1613-b
Large grayscale view of the impact site.
Annotated Image — No Annotation
(C) MOC2-1613-c
Mosaic of multiple high resolution MOC images covering the impact site and its extensive secondary chains and rays.
No Annotation
(D) MOC2-1613-d
Pair of images showing before and after views at MOC red wide angle image scale. The
Annotated Image — No Annotation
NASA/JPL/Malin Space Science Systems

The images of new martian impact craters reveal many details about the impact event that result from the manner in which the impact process interacted with the dusty surface and thin planetary atmosphere; these data are sure to keep scientists busy for years.

Of the 20 new impact craters found on Mars by the Mars Global Surveyor (MGS) Mars Orbiter Camera (MOC) in 2006, the one shown here is perhaps the prettiest. The darkened “blast zone” around the crater exhibits considerable details about how the energy transferred from the impact to the surrounding atmosphere and dust-mantled surface interacted. Wispy dark rays and dark, annular (nearly-circular) zones surround the crater, while several chains of dark spots formed by secondary impact radiate away for hundreds of meters from the tiny crater.

This impact site has a single crater of about 22.6 ± 1.7 meters (about 75 feet) in diameter. Compare this with the typical 100 yard U.S.-style football field: 75 feet is about 24.7 yards. The crater is located in Arabia Terra near 26.4°N, 336.5°W.

(A) The first picture (top, left) is a colorized view of the crater. The image is a sub-frame of MOC narrow angle camera image S16-01674, obtained on 20 March 2006. The color comes from a look-up table derived from the colors of Mars as seen by the Mars Reconnaissance Orbiter’s High Resolution Imaging Science Experiment (HiRISE).

(B) and (C) The second (top, right) and third (middle) pictures are grayscale composites of portions of MOC images S16-01674, S17-00795, S17-02191, and S18-01407, showing the impact site and the extensive rays developed during the impact event. These data were acquired during March, April, and May 2006.

(D) The last picture (bottom) shows how the age of the crater was constrained. The first (left) is a portion of MOC red wide angle camera image R12-00786, acquired on 8 December 2003. The white circle indicates the location of the impact site, but the impact had not yet occurred. The second picture (right) shows the same MOC red wide angle image, overlain by a portion of an image from the Mars Odyssey Thermal Emission Imaging System (THEMIS). The THEMIS image is an infrared picture (I17523014, band 9, ~12.6 micrometers) acquired on 26 November 2005. In the infrared image, the impact site shows up as a bright spot because it is warmer than its surroundings during the day. These two pictures, thus, tell us that the impact occurred some time between 8 December 2003 and 26 November 2005.

Accompanying captioned releases and other material regarding present-day impact cratering on Mars:

Tips for Media Use

Malin Space Science Systems and the California Institute of Technology built the MOC using spare hardware from the Mars Observer mission. MSSS operates the camera from its facilities in San Diego, California. The Jet Propulsion Laboratory's Mars Surveyor Operations Project operates the Mars Global Surveyor spacecraft with its industrial partner, Lockheed Martin Astronautics, from facilities in Pasadena, California and Denver, Colorado.
